DS-2CD1027G2-LUF

2.8 mm, horizontal FOV: 106°, vertical FOV: 57°, diagonal FOV: 126°

4 mm, horizontal FOV: 83°, vertical FOV: 44°, diagonal FOV: 99°

2.8 mm: 1.5 m to ∞

4 mm: 2.1 m to ∞

2.8 mm, D: 44 m, O: 17 m, R: 8 m, I: 4 m

4 mm, D: 56 m, O: 22 m, R: 11 m, I: 5 m

50 Hz: 25 fps (1920 × 1080, 1280 × 720)

60 Hz: 30 fps (1920 × 1080, 1280 × 720)

50 Hz: 25 fps (640 × 480, 640 × 360)

60 Hz: 30 fps (640 × 480, 640 × 360)

Main stream: H.265+/H.265/H.264+/H.264,

Sub-stream: H.265/H.264/MJPEG

Up to 32 users

3 user levels: administrator, operator, and user

Plug-in required live view: IE 10, IE 11,

Local service: Chrome 57.0+, Firefox 52.0+

12 VDC ± 25%, 0.4 A, max. 5 W,Ø5.5 mm coaxial power plug,

PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W

Ø76.6 mm × 164.4 mm (Ø3 × 6.5\")"

-L: Approx. 405 g (0.9 lb.); -LUF: Approx. 425 g (0.9 lb.)

-L: Approx. 630 g (1.4 lb.); -LUF: Approx. 650 g (1.4 lb.)

FCC: 47 CFR Part 15, Subpart B,

CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,

RCM: AS/NZS CISPR 32: 2015,

KC: KN32: 2015, KN35: 2015

UL: UL 62368-1,

CB: IEC 62368-1: 2014+A11,

CE-LVD: EN 62368-1: 2014/A11: 2017,

BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005

CE-RoHS: 2011/65/EU,

WEEE: 2012/19/EU,

Reach: Regulation (EC) No 1907/2006
