| מקשים | שמע | אזעקה (I/O) | קורא כרטיסים | תקשורת | RS-485 | חומר | מתח עבודה | מידות (L x W x H) |
| Physical Button | מיקרופון ורמקול מובנים | 4 Input | 1 X 10/100 RJ-45 | module connection with RS-485 | פלסטיק | DC 12V / PoE | 98 × 99.8 × 43.9 mm |
| CE-EMC | a. EN 55032:2015
b. EN 61000-3-2:2014 c. EN 61000-3-3:2013 |
| CE-LVD | EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 |
| CB | IEC 60950-1:2005 (Second Edition) + Am 1:2009
+ Am 2:2013 |
| FCC-SDOC | 47 CFR Part 15, Subpart B |
| C-
TICK(EMC) |
AS/NZS CISPR 32:2015 |
| UL | UL 60950-1 & CAN/CSA C22.2 No. 60950-1-07,
Information Technology Equipment – Safety – Part 1: General Requirements |
| ROHS | 2011/65/EU |
| REACH | Regulation (EC) No 1907/2006 |
| WEEE | 2012/19/EU |
| דגם | תאור | סדרה | הגנה | פרטים נוספים | מסך |
| DS-KD8003-IME1 | מודול דלת כניסה | דור 2 | IP65 | 2MP Camera + IR , Standard PoE , ניתן לשייך ל-6 מסכים |
Approval Specification
554 g (with packaging) 375 g (without packaging)
| System parameters | |
| Processor | Embedded MCU Processor |
| Operation system | Embedded Linux operation system |
| Operation
method |
Physical button |
| Video Parameters | |
| Camera | Low illumination 2 MP HD IR camera |
| Video Compression
Standard |
H.264 |
| Resolution | Main stream : 1920 × 1080
Sub stream : 720 × 480 |
| BLC | Supported |
| DNR | Supported |
| WDR | Supported |
| Anti-flicker | 50 Hz, 60 Hz |
| Field of view | Horizontal: 180° Vertical: 96° |
| Audio parameters | |
| Audio input | Built-in omnidirectional microphone |
| Audio output | Built-in loudspeaker (More than 85 dB
within 20 cm) |
| Audio compression standard | G.711 U |
| Audio
compression Rate |
64 Kbps |
| Audio quality | Noise suppression and echo cancellation |
| Light supplement | |
| Light supplement
mode |
IR supplement |
| Network parameters | |
| Ethernet | 10/100 Mbps self-adaptive Ethernet |
| Network | TCP/IP, RSTP |
| Alarm parameters | |
| Tampering
alarm |
1 |
| Interfaces | |
| Module-
connecting |
1 |
| I/O input | 4 |
| Debug | 1 |
| Relay | 2 (30 V, 1 A) |
| General | |
| Physical button | 1 |
| Power supply | 12 VDC/PoE (IEEE 802.3af) |
| Power | ≤ 10 W |
| Working temperature | -40° C to +55° C(-40° F to 131° F) |
| Working humidity | 10% to 95% |
| Installation | Flush mounting, surface mounting |
| Dimension | 98 mm × 99.8 mm × 43.9 mm (3.86" ×
3.93" × 1.73") |
DS-KD8003-IME1
| No. | Description | No. | Description |
| 1 | Microphone | 6 | Nametag |
| 2 | Low Illumination IR
Supplement Light |
7 | TAMPER |
| 3 | Built-in Camera | 8 | Network Interface |
| 4 | Loudspeaker | 9 | Module-connecting |
| 5 | Call Button | 10 | Terminals |
| Optional | |
 |
 |
| DS-KD-ACF1/Plastic | DS-KD-ACF2/Plastic |
|
|
|
| DS-KD-ACF3/Plastic | DS-KD-ACW1 |
|
|
 |
| DS-KD-ACW2 | DS-KD-ACW3 |
אחריות יצרן/יבואן (בחודשים) |
24 |
|---|
