F35 – Standalone Access Control Terminal with Video Intercom

  • Zkteco
  • 10,000 (1:N)
  • 2.4"@ TFT Color LCD Screen (720*1280)
  • 2-megapixel
  • 195 mm*75 mm*25.35 mm (L*W*H)
  • DC 12V, 3A
  • 0.52 Kg

המחיר שלנו

מחיר משלוח: עד הבית/עסק UPS (עד 5 ק"ג): 50
*התמונות והתיאור באתר להמחשה בלבד. *מבוסס על AI ויכול לטעות (טל"ח). *יש להסתמך על מפרט הטכני הרשמי של היצרן​.

תיאור

F35

Standalone Access Control Terminal with Video Intercom

Overview

F35 from ZKTeco is a standalone access control terminal featuring a video intercom function. F35 adopts in-glass fingerprint verification, offering secure biometric authentication without a dedicated button.

F35 also supports multiple tech card modules for verification, and it can be a time and attendance terminal when integrated with the BioTime software.

Also, one of the notable features of the F35 is that it has a 2.4-inch color monitor, a 2MP camera, a built-in microphone, and speakers for one-way video intercom via indoor monitor with SIP protocol. F35 supports the ONVIF protocol; its firmware has AC push and can convert to TA push.

The aluminium alloy frame of the F35 offers robust protection, and it attained an IP65 protection rating, guaranteeing that this terminal operates in adverse weather.

Functions

  • In-glass fingerprint verification.
  • Aluminium alloy frame and 2.5D glass panel.
  • Support SIP Client (Ver2.0) for one-way video intercom.
  • Fully compatible with ZKTeco SIP Video intercom indoor monitor (VT07-B01and VT07- B01-W)
  • Attained IP65 protection rating with dustproof and waterproof.
  • Communication: TCP/IP and Wi-Fi (Optional).
  • Support video talk via mobile app: ZSmart.
  • Available card modules: 125 kHz ID card (standard) / 125 kHz ID card & 13.56MHz IC card (optional) / Multi tech card (optional): 125kHz & 13.56MHz ID & IC card & DESFire EV1 / EV2 / Felica / HID proxy / HID ICLASS.
  • Multiple Verification Methods: Fingerprint / Card / Password.
  • Support AC push and convert to TA push.
  • Support Doorbell and Wireless Doorbell (Optional).

Specifications

Model F35
Display 2.4" TFT Color LCD Screen (720*1280)
Camera 2MP; Field of View (Diagonal: 145° / Horizontal: 118° / Vertical: 62°)
Operation System Linux
Hardware CPU: 1.2GHz Dual Core; RAM: 256MB; ROM: 512MB; In-Glass Fingerprint (Z-ID); Speaker (1.0W); Omni-directional Mic
Authentication Method Fingerprint / Card / Password (Physical Touch Keypad)
Capacity Users: 10,000 | Cards: 10,000 | Fingerprints: 10,000 | Transactions: 500,000
Biometric Performance Speed: < 0.3s | FAR ≤ 0.0001% | FRR ≤ 0.01% (ZKFingerprint V10.0)
Card Support Standard: ID (125kHz); Optional Multi-Tech: IC, DESFire EV1/EV2, FeliCa, Legic, HID Prox, HID iClass
Communication TCP/IP, Wi-Fi (2.4GHz), Wiegand In/Out, RS485
Access Control I/O Electric Lock, Door Sensor, Exit Button, Alarm, Doorbell, Aux I/O
Standard Functions Webserver, ADMS, ONVIF (S, T, G, C, Q, A), Video Door Phone, Anti-Passback, HTTPS/SSH
Operating Environment Temp: -5°C to 55°C | Humidity: 10% to 90% RH
Protection Rating IP65 (Waterproof/Dustproof), IK04 (Vandal Resistant)
Dimensions & Build 195 x 75 x 25.35 mm; Aluminum Alloy Housing; Net Weight: 0.52 Kg
Supported Software ZKBio CVSecurity, BioTime, ZSmart App

Downloads

מידע נוסף

Manufacturers

User Capacity

10,000 (1:N)

Display

2.4"@ TFT Color LCD Screen (720*1280)

Resolution

Dimensions

195 mm*75 mm*25.35 mm (L*W*H)

Power Supply

DC 12V, 3A

Net weight

0.52 Kg
