Tiny yet Powerful
2/5/8MP · 140dB Super WDR · 0.002Lux Ultra Low-light · IP67 · IK10 · 50m IR Distance · 60fps · PoE · Versatile Interfaces
Milesight VCA with 10 detection modes provides advanced, accurate smart video analysis for Milesight network cameras, enabling the comprehensive surveillance function and quicker response to different monitoring scenes.
Applied with 2.8mm ultra wide angle lens, the camera is able to catch more than 120° field of view, which is the leading level of the industry. And the resolution up to 4K guarantees superior image details even under wide angles.
Milesight 4K H.265+ Mini Bullet Network Camera delivers up to 4K resolution (3840*2160, effectively four times that of Full HD) at 15 frames per second (fps), providing users with ultra-high-definition video viewing experience.
The starlight camera is able to deliver high detailed color images even in the low light environments reaching 0.002Lux (Color) or 0Lux (B/W), and near infrared light environments without any supplementary lighting.
Milesight’s sensor-based WDR technology allows the Mini Bullet Network Camera to record greater scene details with true color reproduction even under the extreme back light and high contrast conditions. The ratio that the brightest light signal values divided by the darkest light signal values is up to 140dB.
To maximize the IR performance, the H.265+ Mini Bullet Camera innovated both in the structure and technology. The advanced Smart IR II technology with 50m IR distance, guarantees IR performance with adjustable illumination intensity. The infrared light transmittance is greatly increased with IR anti-reflection panel which is well designed for better IR effect.
Milesight H.265+ Mini Bullet Camera offers high frame rate including 60fps@2MP, 30fps@5MP and 30fps@4K, which enables the camera to easily catch images with no latency despite the high-speed movement.
This stylishly designed H.265+ Mini Bullet Network Camera has a unique outdoor housing sunshield that almost encircles the camera body, which effectively blocks the sun from entering the lens path and offers great thermal insulation.
Supporting industry-leading IP67-rated weather proofing and IK10-rated vandal proofing, the H.265+ Mini Bullet Network Camera is well protected against adverse impacts to ensure the performance.
Milesight H.265+ Mini Bullet Network Camera incorporates IEEE 802.3af Power over Ethernet module inside the body which offers easy installation for Standard Version by providing power and networking connectivity with a single cable.
Several interfaces such as PoE, DC, Audio I/O and Alarm I/O are available in the Multi-interface Version, offering more choices for easy management and various needs.
The H.265+ Mini Bullet Network Camera is easy to install on a wall or ceiling. It features 3-axis bracket which provides a robust mounting platform for tidy installation and camera angle adjustments on a 3-axis plane.
Milesight H.265+ Mini Bullet Network Camera features industry leading SIP/VoIP function and video streaming for mobile phones and video phones.
Name2MP H.265 Mini Bullet Network Camera
Image Sensor1/2.8" Progressive Scan CMOS
Min. IlluminationColor: 0.002Lux @F1.2, Color: 0.005Lux @F1.6, B/W: 0Lux with IR on
WDR140dB Super WDR
Lens4mm/2.8mm/6mm @F1.6
Field of ViewH91°/D106°/V50°(4mm), H111°/D128°/V61°(2.8mm), H55°/D63°/V32°(6mm)
Shutter Time1/100000s∼1s
Day/Night ModeDay/Night/Auto/Customize/Schedule
IR DistanceUp to 50m
S/N>55dB
Max. Image Resolution1920×1080
Frame Rate60fps@(1920×1080)(Optional for R Series), 30fps@(1920×1080, 1280×960, 1280×720, 704×576)
Secondary Stream30fps@(704×576, 640×480, 640×360, 352×288, 320×240, 320×192, 320×180)
Tertiary Stream30fps@(1920×1080, 1280×720, 704×576, 640×480, 640×360, 320×240, 320×192, 320×180)
Video CompressionH.265+/H.265(HEVC)/H.264+/H.264/MJPEG
Video Bit Rate16Kbps∼16Mbps (CBR/VBR adjustable)
Privacy MaskingUp to 8 areas
ROIUp to 8 areas
Image SettingsSaturation/Brightness/Contrast/Sharpness
Audio CompressionG.711/AAC/G.722/G.726
Audio Sampling Rate8/16/32/44.1/48KHz(44.1KHz is available for all except R Series)
Audio Bit Rate16~256kbps
Two-way AudioSupport
Ethernet1*RJ45 10M/100M Ethernet Port
Audio I/O1/1(Multi-interface Version)
Alarm I/O1/1(Multi-interface Version)
Network StorageNAS(Support NFS, SMB/CIFS), ANR
Network ProtocolsIPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, UPnP, Bonjour, SIP, SNMP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL
StorageSupport microSD/SDHC/SDXC Card Local Storage, up to 256G
Advanced FunctionBLC, HLC, 2D DNR, 3D DNR, Defog, AWB, EIS, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Deblur, Watermark
SIP/VoIP SupportYes, Voice&Video-over-IP
Event TriggerMotion Detection, Network Disconnection, etc.;
Motion Detection, Network Disconnection, External Input, Audio Alarm, etc. (Multi-interface Version)
Event ActionFTP Upload, SMTP Upload, SD Card Record, SIP Phone, HTTP Notification, etc.;
FTP Upload, SMTP Upload, SD Card Record, External Output, SIP Phone, HTTP Notification, etc. (Multi-interface Version)
Video AnalysisRegion Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Human Detection, People Counting, Object Left, Object Removed
System CompatibilityONVIF Profile G & Q & S & T, API
Working Temperature-40℃∼60℃
Working Humidity0∼90%(Non-condensing)
Power SupplyPoE(802.3af);
PoE (802.3af) / DC 12V±10% (Multi-interface Version)
Power Consumption4W MAX, 5.5W MAX (With IR on)
Weather ProofUp to IP67-rated for weather-resistant performance
HousingVandal-proof IK10-rated metal housing
DimensionsΦ76mmX214.5mm
Weight750g
Warranty3/5 Years
* Naming Convention
H – 30fps@5MP/4K Series
R – High Frame Rate (60fps)
P – PoE Supported
B – H.265 Compression
