P3 Mini 4G wireless bonding encoder is the ideal solution for outdoor live streaming, built on patented KiloLink bonding transmission technology and serving as an upgraded version of the P1/P2 models. It features a professional-grade antenna isolation design, enabling the effective bonding of multiple networks — supporting 3×4G cellular, 1×Wi-Fi, and 1×RJ45 Ethernet — for enhanced anti-interference and stable transmission performance.
The P3 Mini features 3G-SDI/HDMI/USB multiple inputs , supporting up to 1080p60 resolution. It also comes with a 4900 mAh battery for up to 4 hours of continuous operation, along with PD fast charging support, making it suitable for a wide range of application scenarios.
The P3 Mini supports both H.265 and H.264 encoding formats, and features three video input interfaces: HDMI, 3G-SDI, and USB, supporting resolutions up to 1080p60. It offers full compatibility with leading streaming protocols, including NDI HX2, RTSP, RTMP/RTMPS, SRT, HLS, WHIP, and TS over UDP.
Paired with the KiloLink Server Pro, the P3 Mini enables stable, high-quality, and low-latency streaming across multiple mainstream live platforms — all at the same time.
Outdoor live streaming, outdoor program production, news reporting, emergency command, vehicle-mounted mobile video transmission, multi-media project engineering, hospital external network video transmission, and other scenarios requiring wireless video transmission.
| Model | P3 Mini |
| Video Resolution | HDMI & SDI Input: Up to 1080p 60fps / 1080i 60fps / SD (PAL & NTSC) USB Input: Up to 1080p 60fps |
| Video Ports | 1× 3G-SDI, 1× HDMI 1.4b, 1× USB-A/USB-C |
| Encoding & Protocols | Codecs: H.265 (HEVC), H.264 (AVC), M-JPEG Protocols: NDI HX2 / HX3*, SRT, RTMP, RTMPS, HLS, TS over UDP, RTSP *HX3 support via future firmware. |
| Bonding & Wireless | Performance: 3 channels of 4G cellular + Wi-Fi (2.4G/5G) + Ethernet Connectivity: 3× 4G modules, 1× Wi-Fi 5 module, 1× 1000Mbps RJ45 |
| Audio Port & Channels | 1× 3.5mm Line In | 4-ch embedded audio (SDI/HDMI/USB) | 2-ch Line In |
| Physical Controls | 3" LCD touchscreen for local monitoring and setup |
| Battery & Power | Battery: 4900mAh (Approx. 4 hours runtime) Power: DC 12V/3A, PD-compliant |
| Features & Management | Web UI / Kilolink Server | Rotation, Mirroring, Cropping | OSD Overlays | Voice Intercom (KIS) |
| PTZ & Storage | PTZ: RS-232/485/422, Network (Visca/Pelco), UVC support Storage: External USB or NAS (MP4, MOV, TS) |
| Physical Specs | Weight: 600g | Dimensions: 138x85x35mm Temp Range: -15℃ to 45℃ |
